ASTM D6110 Digital Impact Testing Machine , CHARPY Impact Test Machine

Name: ASTM D6110 Digital Impact Testing Machine CHARPY Impact Test Machine
Brand: Infinity Machine
Price: 1 USD

Buy cheap ASTM D6110 Digital Impact Testing Machine , CHARPY Impact Test Machine product

Brand Name : Infinity Machine

Model Number : RS-8215B

Certification : CE

Place of Origin : Made in China

MOQ : 1 set

Price : Negotiable

Payment Terms : D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200 sets per month

Delivery Time : Shipped in 15 days after payment

Packaging Details : Standard export wooden case with operation manual and video inside.

Function : CHARPY Digital Impact Test

Capacity : 1J, 2J, 4J (standard)

Test angle : 150°

Impact speed : 2.9m/sec

Angle accuracy : 0.1°

Energy accuracy : 0.001 J

Print out : Capacity. Angle, energy, etc.

Dimension : 680x410x760mm

Contact Now

ASTM D6110 Digital Impact Testing Machine , CHARPY Impact Test Machine

Model: RS-8215B

Application:

This tester is to measure the impact-resistance of the specimens of various tough materials which endure the impact at specified angle and load.

Test standards:

CHARPY: ASTM D6110, ISO 179, GB/T1043

Features:

After test, test results show automatically and they can be saved or printed out.

After test, it shows the angle and energy automatically.

There are safety protection device and press button controlling the Impact action.

Specification:

Model	RS-8215B
Function	CHARPY Digital Impact Tester
Capacity	1J, 2J, 4J	Standard
	7.5J, 15J	Optional
Test angle	150°
Impact speed	2.9m/sec,
Effective length of pendulum	22.96cm,
Angle accuracy	0.1°
Energy accuracy	0.001 J
Energy unit	Kg-mm, kg-cm, kg-m, Ib-ft, Joule(N-m)
Dimension(WxDxH)	680x410x760mm
Print out	Capacity. Angle, energy, etc.
Weight	About 90kg
Power supply	AC220V 50Hz 3A or specified by user

Package:
