Computerised LCD Touch Panel Tester for Rolling Click Crossed Test

Name: Computerised LCD Touch Panel Tester for Rolling Click Crossed Test
Brand: Infinity Machine
Price: 1 USD

Brand Name : Infinity Machine

Model Number : RS-5610C

Certification : CE, ISO

Place of Origin : Made in China

MOQ : 1 set

Price : Negotiable

Payment Terms : D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200 sets per month

Delivery Time : Shipped in 15 days after payment

Packaging Details : Standard export wooden case with operation manual and video inside.

Controller : Computer Control

X axis movement range : 0~150mm or 0~300 (specified before order)

Y axis movement range : 0~150mm or 0~300 (specified before order)

Z-axis click cylinder : 0~20mm

Load : 20g, 30g, 150g, 250g

Dimension : 750x750x660mm

Weight : About 120kg

Power source : AC220V 50Hz 5A or specified by user

Contact Now

Computerised LCD Touch Panel Tester for Rolling Click Crossed Test

Model: RS-5610C

Purpose:

This machine is used for pressing rolling, clicking, Drawing test for small LCD, touching screen, such as mobile phone.

Test Item:

Touching pen clicking test: 0-15N(or set).

Touching pen drawing test: drawing line on touching screen as setting.;

Mobile surface abrasion test: with alcohol / eraser as testing assistance.

Specification:

Model	RS-5610C ( Computer Control )
X-axis Moving range	0~150mm or 0~300 (specified before order)
Y-axis Moving range	0~150mm or 0~300 (specified before order)
Z-axis click cylinder	0~20mm
Positioning accuracy	0.05mm
Moving speed	0~200mm/sec
Pressure range	80~1500gf (or specified)
Load	20g, 30g, 150g, 250g
Air pressure	≥0.5MPa
Dimension (WxDxH)	750x750x660mm
Weight	About 120kg
Power supply	AC220V 50Hz 5A or specified by user

Fixture:

Test reports:
