Abrasion Resistant Rubber Rotary Abrasion Tester / Taber Abrasion Machine

Name: Abrasion Resistant Rubber Rotary Abrasion Tester Taber Abrasion Machine
Brand: Infinity Machine
Price: 1 USD

Brand Name : Infinity Machine

Model Number : RS-8201

Certification : CE， ISO

Place of Origin : Made in China

MOQ : 1 set

Price : Negotiable

Payment Terms : D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200 sets per month

Delivery Time : Shipped in 15 days after payment

Packaging Details : Standard export wooden case with operation manual and video inside.

Specimen : ∮16mm, 6x15mm(D)

Grip : 2.5N

Weight : 95kg

Dia. Of drum : 150mm

Speed of drum : 40rpm

Dimension : 800x390x480mm

Power : AC220V 3A or specified by user

Contact Now

Abrasion Resistant Rubber Rotary Abrasion Tester / Taber Abrasion Machine

Model: RS-8201

Purpose:

This tester is manufactured according to the standards such as DIN-53516, ISO/DIS-4649, BS903PART9, GB-9867and so on for testing the abrasion of those plastic and rubber materials and is also suitable for the comparison testing and verifying the uniformity and the classifying of products.

Abrasion Resistant Rubber Rotary Abrasion Tester / Taber Abrasion Machine

Principle:

To test the abrasion of the testing sample under regulated force imposed against fixed area occurs on the sand papers of various grades through various angles.

Sand paper is stick around the surface of roller, and the testing sample is compressed onto the roller of which is wrap with sand paper, and let the testing sample move horizontally around roller, and according abrasion will happens with testing sample, measure the abrasion loss of testing sample and work out the unit abrasion loss according to the density of testing sample.

Specification:

Model	RS-8201
Standard	DIN-53516, ISO/DIS-4649, GB-9867 SATRA TM174 BS903 JIS K6264
Specimen	∮16mm, 6x15mm(D)
Grip	2.5N
Weight	2.5N, 5N, 10N
Grip horizontal displacement	4.2mm (per rotation of drum)
Dia. Of drum	150mm
Length of drum	460mm
Speed of drum	40rpm
Abrasion path	40m/20m correspond to rotations of the drum
Abrasion speed	0.32m/sec.
Inclination	3° between the shaft and specimen support rod
Dimension (WxDxH)	800x390x480mm
Weight	95kg
Power	AC220V 3A or specified by user
